The 2 ports fiber distribution box is a wall mount 12 fiber enclosure designed to joint optical cable with pigtail and provides protection in indoor or outdoor environments. It enables the direct connection of pre-terminated drop cable or branch connection through the fusion splicing with pigtail, also used to realize terminal connection. Mechanical & fusion splicing, termination and storage can be done within the indoor/outdoor enclosure which widely used in the fiber to the home (FTTH) network project.
This optical distribution box comes with 2 input and 2 output ports, supporting 12 cores splicing and termination for FTTH, FTTB systems. It is of quality engineering plastics and keep it from damage ; stainless lock secure the fiber termination box; multi-layer design is clear for fiber operation; a separate splice cassette is installed in the box for convenient splicing and wiring.
. Made of PP plastics
. Independent splice tray is convenient for splicing and storage
. Enough space for cable storage and fiber routing
. Flip design for adaptor panel providing easy fiber management
. Waterproof, dustproof, Protection level up to IP65
|Cable diameter (mm)
|Max splice capacity
|12 cores (single)
|5 days for 100pcs, 10 days for 800pcs
