This small aerial fiber optic joint enclosure comes with 2 ports on both ends for optical cable in and out, can hold 12 cores of fiber splicing and connection. The main body of the splice case is of quality engineering plastics, and it features lightweight, high mechanical strength, anti-aging, strong corrosion-resistance; Inside fiber optic enclosure can hold 1 pc 24 splice tray for managing splices and excess fibers. This fiber joint box has an independent insulation grounding device, so can make the cable grounding flexible, convenient, and safe. The fiber optic splice closure is used for direct and splitting connection during optical fiber transmission and provides cable joint protection; In addition, it is also applied to the connection of all-plastic city phone cables.
The small fiber optic enclosure integrates the function of distribution, splice, joint, and storage of outdoor optical fiber cable which entry and exit from the end of the closure, and can be applied in aerial, duct, pole, wall mount, underground direct buried fibre optic cable projects.
Specification:
Size(mm) | 245*150*30 | Product Type | Horizontal |
Max capacity | 24 cores(single fiber ) | Tray capacity | 24 cores |
Splice tray | 1 | Sealing type | Silicone rubber |
Cable diameter(mm) | Φ7-10 | Entry&Exit | 2 inlet/2 outlet |
